Zinc-Coated Steel Wire Strand (Galvanized Steel Wire Strand)

Galvanized Steel Wire Overhead Ground Wire Static Wire Zinc-Coated Transmission Line

We offer to our clients superior quality of galvanized steel strand wire, which are extensively used as overhead ground wire or static wires.

ISO 9001 ASTM BS IEC

Product Introduction

We offer to our clients superior quality of galvanized steel strand wire, which are extensively used as overhead ground wire or static wires.

• Overhead transmission line.
• Guying of Pole.
• Earthing of the overhead transmission line.

Manufactured according to international standards including ASTM A475 and BS 183:1972, ensuring consistent quality and performance.

Nominal Diameter Of strand in {mm}	Number of wires in wire	Nominal Diameter of Coated Wire in Strand in (mm)	Approximate Weight of Strand lb/1000ft (kg/km)	Utilities grade	Minimum Breaking Grade	Strength of Strand. lbf[kN]	High-Strength Grade	Extra High-Strength Grade
1 / 8	[3.18]	7	0.041[1.04]	32	[48]	540[2.402]	910[4.048]	1330[5.916]	1830[8.140]
5 / 32	[3.97]	7	0.052[1.32]	51	[76]	870[3.870]	1470[6.539]	2140[9.519]	2940[13.078]
3 / 16	[4.76]	7	0.062[1.57]	73	[109]	1150[5.115]	1900[8.452]	2850[12.677]	3990[17.748]
3 / 16	[4.76]	7	0.065[1.65]	80	[119]
7 / 32	[5.56]	3	0.104[2.64]	88	[131]	1400[6.228]	2340[10.409]	3500[15.569]	4900[21.796]
7 / 32	[5.56]	7	0.072[1.83]	98	[146]	1540[6.850]	2560[11.387]	3850[17.126]	5400[24.020]
1 / 4	[6.35]	3	0.120[3.05]	117	[174]	3150[14.012](2)	1860[8.274]	3040[13.523]	4730[21.040]	6740[29.981]
1 / 4	[6.35]	3	0.120[3.05]	117	[174]	4500[20.017](3)
1 / 4	[6.35]	7	0.080[2.03]	121	[180]	1900[8.452]	3150[14.012]	4750[21.129]	6650[29.581]
9 / 32	[7.14]	3	0.130[3.30]	137	[204]	2080[9.252]	3380[15.035]	5260[23.398]	7500[33.362]
9 / 32	[7.14]	7	0.093[2.36]	164	[244]	4600[20.462](1)	2570[11.432]	4250[18.905]	6400[28.469]	8950[39.812]
5 / 16	[7.94]	3	0.145[3.68]	171	[255]	6500[28.913](3)	2490[11.076]	4090[18.193]	6350[28.246]	9100[40.479]
5 / 16	[7.94]	7	0.104[2.64]	205	[305]	3200[14.234]	5350[23.798]	8000[35.586]	11200[49.820]
5 / 16	[7.94]	7	0.109[2.77]	225	[335]	6000[26.689](1)
3 / 8	[9.52]	3	0.165[4.19]	220	[328]	8500[37.810](3)	3330[14.813]	5560[24.732]	8360[37.187]	11800[52.4869]
3 / 8	[9.52]	7	0.120[3.05]	273	[406]

Overhead transmission line

Guying of Pole

Earthing of the overhead transmission line

Static wires

Ground wire applications

All cables will be packaged in different materials based on their outer diameter and net weight, and can be customized according to requirements
